MUTLIECUSCAN 6 Cable Set

Description

In addition we offer an optional 6 cable set that will allow you to connect to other functions:

For use with Multiecuscan software. You must have the OBD cable to adapt to these.

FiatECUScan Adapter Cable Bundle

Cable length: 22cm

Note: There are only used as a connector cable and does not contain any software or diagnostic cables

There are 6 adaptor cables included which perform different functions.

Green ABS / Power Steering adapter lead ( “Adapter 1” on MultiECUScan website)

-Designed to allow access to the ABS and Power Steering systems on supported vehicles. This adapter has a green connector on one end for easy identification.

Using this adapter, Pin 7 on the diagnostic tool is connected to Pins 1,7,9 & 12 on the car.

Red Airbag adapter lead ( “Adapter 2” on MultiECUScan website)

-Designed to allow access to the Airbag system on supported vehicles.

This adapter has a red connector on one end for easy identification.

Using this adapter, Pin 7 on the diagnostic tool is connected to pin 3 only pn the car.

Yellow CAN adapter lead ( “Adapter 3” on MultiECUScan website)

-Designed to allow access to the low-speed CAN system on supported vehicles.

This adapter has a yellow connector on one end for easy identification.

Using this adapter, Pin 6 & 14 on the diagnostic tool are connected to pins 1 & 9

Respectively on the car, Pin 7 on the diagnostic tool is connected to pin 12 on the car.

Purple Electric hood adapter lead ( “Adapter 4” on MultiECUScan website)

-Designed to allow access to the electric hood system on supported vehicles.

This adapter has a purple connector on the end for easy identification.

Using this adapter, Pin 7 on the diagnostic tool is connected to pins 7,8,11 & 13 one the car.

Blue Control Module Adapter Wire Design allows access to enhanced features on the vehicle (eg, multimedia, blind spot sensors, etc.)

Gray base control module adapter wire designed to allow access to basic functions on the vehicle (eg headlights, parking controller, ABS, electric steering, etc.)

Packing List:

6 x ECU connector cables for Fiat

PROFESSIONAL FOR FIATECU SCAN ADAPTER OBD OBD2 CONNECTOR MULTI SCAN ABS AIRBAG OBD2 SCANNER DIAGNOSTIC CABLE FOR FIAT ECU SCAN
